| ENGINE
				 +
			    |

| Engine	 | 650 |
| Engine displacement	 | 650 |
| Type	 | 650: 59 hp ( 44 kW ), Rotax 649.6 cc V-twin, liquid cooled |
| Fuel Delivery System	 | Intelligent Throttle Control (iTC™) with Electronic Fuel Injection (EFI) |
| Transmission	 | CVT, P / R / N / H / Extra low L, standard engine braking |
| Drive Train	 | Selectable 4WD / 6WD with Visco-Lok QE† auto-locking front Differential
 Selectable 4WD / 6WD with Visco-Lok‡ QE auto-locking front Differential |
| Power Steering	 | Tri-Mode Dynamic Power Steering (DPS) |
			| SUSPENSION
				 +
			    |

| Front Suspension	 | Arched double A-arm with front sway bar 9.2 in. (23.3cm) travel |
| Front Shocks	 | Oil |
| Rear Suspension	 | Double Torsional Trailing arm Independent (TTI2) with quick-release sway bar 9.9 in. (25,1 cm) travel |
| Rear Shocks	 | Oil |
			| TIRES/WHEELS
				 +
			    |

| Front Tires	 | Carlisle ACT HD 26 x 8 x 12 in. (66 x 20.3 x 30.5 cm) |
| Rear Tires	 | Carlisle ACT HD 26 x 10 x 12 in. (66 x 25.4 x 30.5 cm) |
| Wheels	 | 12 in. cast-aluminum |
			| BRAKES
				 +
			    |

| Front	 | Dual 214 mm ventilated disc brakes with hydraulic twin-piston calipers |
| Rear	 | Single 214 mm ventilated disc brake with hydraulic twin-piston caliper |
			| DIMENSIONS / CAPACITIES
				 +
			    |

| L x W x H	 | 297 x 122 x 126 cm |
| Wheel Base	 | 208 cm |
| Ground Clearance	 | 11 in. (27.9 cm) |
| Dry Weight	 | 574 kg |
| Rack Capacity	 | Front: 100 lb (45 kg) / Rear: 700 lb (318 kg) |
| Storage Capacity	 | Dual-level cargo box with sidewalls and tailgate Rear: 18.5 gal (70 L) |
| Towing Capacity	 | 907 kg trailer with brakes and 674 kg trailer without brakes |
| Fuel Capacity	 | 5.4 gal (20.5 L) |
| Seat Height	 | 34.5 in. (87.7 cm) |
			| FEATURES
				 +
			    |

| Gauge	 | 4.5-in. digital display : Speedometer, tachometer, odometer, trip & hour meters,gear position, 4 x 4 indicator, temperature, engine lights, electronic fuel gauge & clock |
| Instrumentation	 | Lighter type DC outlet in console, standard connector in the back (15-A) |
| Anti Theft System	 | Digitally Encoded Security System (D.E.S.S.™) |
| Lighting	 | 230 W from twin 60-W projectors and dual 55-W reflectors with tail light / brake light |
| Winch	 | 3,500-lb (1,588 kg) winch |
| Seat	 | Reinforced seat skin |
| Protection	 | Heated hand grips |
			| WARRANTY
				 +
			    |

| Factory	 | 2 years BRP limited warranty |
