| ENGINE
+
|
| Engine | 1000R |
| Engine displacement | 1000 |
| Type | 101 hp / 69 lb-ft, Rotax® 999 cc V-twin, DOHC, liquid cooled |
| Fuel Delivery System | Intelligent Throttle Control (iTC™️) with Electronic Fuel Injection (EFI) |
| Transmission | CVT, P / R / N / H / L, standard engine braking |
| Drive Train | Selectable 2WD / 4WD with Brake Traction Control (BTC) |
| Power Steering | Tri-Mode Dynamic Power Steering (DPS) |
| SUSPENSION
+
|
| Front Suspension | Arched double A-arm with front sway bar 9.2 in. (23.3cm) travel |
| Front Shocks | FOX† 1.5 PODIUM† QS3 |
| Rear Suspension | Torsional Trailing arm Independent (TTI) 9.9 in. (25,1 cm) travel |
| Rear Shocks | FOX† 1.5 PODIUM† QS3 |
| TIRES/WHEELS
+
|
| Front Tires | ITP† Terracross 26 x 8 x 14 in. (66 x 20.3 x 35.6 cm) |
| Rear Tires | ITP† Terracross 26 x 10 x 14 in. (66 x 25.4 x 35.6 cm) |
| Wheels |
14 in. cast-aluminum beadlock |
| BRAKES
+
|
| Front | Dual 214 mm ventilated disc brakes with hydraulic twin-piston calipers |
| Rear | Single 214 mm ventilated disc brake with hydraulic twin-piston caliper |
| DIMENSIONS / CAPACITIES
+
|
| L x W x H | 94 x 48 x 53 in. (238.8 x 121.9 x 135 cm) |
| Wheel Base | 59 in. (149.9 cm) |
| Ground Clearance | 11 in. (27.9 cm) |
| Dry Weight | 900 lb (408 kg) |
| Rack Capacity | Front: 100 lb (45 kg) / Rear: 200 lb (90 kg) |
| Storage Capacity | Rear: 5.7 gal (21.4 L) |
| Towing Capacity | 750 kg trailer with brakes 395 kg trailer without brakes |
| Fuel Capacity | 5.4 gal (20.5 L) |
| Seat Height | 34.5 in. (87.7 cm) |
| FEATURES
+
|
| Gauge | 7.6-in wide digital display : Speedometer, tachometer, odometer, trips & hour meters, gear position, 4 x 4 indicator, temperature, engine lights, electronic fuel gauge, clock |
| Instrumentation | Lighter type DC outlet in console, standard connector in the back (15-A) |
| Anti Theft System | RF Digitally Encoded Security System (D.E.S.S.™) |
| Lighting | 230 W from twin 60-W projectors and dual 55-W reflectors with tail light / brake light |
| Winch | 1,588 kg (3,500 lbs) winch with roller fairlead |
| Seat | Convertible Rack System (CRS) |
| Protection | Heavy-duty front & rear bumpers, mudguards, aluminum taper-profile handlebar with wind deflectors and square pad |
| WARRANTY
+
|
| Factory | 2 years BRP limited warranty |
